Forgestar CF10 Wheels for Subaru Applications
ModBargains now sells some of the most
popular sizes in the Forgestar CF10 lineup. This means you can have
a set of infamous Forgestar CF10 wheels for your Subaru with NO 6-8 week
lead time. Come in and get a set of these fresh CF10 wheels
installed today or have a set shipped to you today! Get your set
before we run out; these are already flying off of our shelves.

|
"Talk about a head turning wheel!! The Forgestar CF10 is one of
my favorite wheels of all time. I have received so many
compliments on these wheels. I have these wheels on my own
personal car and absolutely love the way they make my car look.
Once I took the boring stock wheels off my car and replaced them
with the Forgestar CF10's, my car had a completely different
personality. It was suddenly aggressive, but clean. It was just
downright impressive. If you're thinking about these wheels,
just do it, I promise you that you will love them on your own
car just like I love them on mine!"
- Mike Brown, Co-Founder & CEO |
Please note the Forgestar CF10 Wheels will require
cone seat lug bolts so that the wheels sit properly on the hub. We can
provide these for you (see attributes).

ATTENTION:
FILL IN YOUR VEHICLE INFORMATION AND OFFSETS IN THE TEXT BOX ABOVE!
Subaru Vehicles with
5x100 Bolt Pattern:
1997-2011 Subaru Forester
1993-2014 Subaru Impreza
2002-2014 Subaru Impreza WRX
2003-2004 Subaru Impreza STI
2010-2011 Subaru Impreza 2.5
1990-2011 Subaru Legacy
2000-2009 Subaru Legacy GT
1995-2007 Subaru Outback Wagon
2005-2014 Subaru Outback |
Subaru Vehicles with 5x114.3 Bolt Pattern:
2005-2014 Subaru Impreza STI
2015-Present Subaru WRX
2015-Present Subaru WRX STI
2013-Present Subaru BRZ
|

|

Features:

- High Quality flow form production
- Durability of a Forged Wheel
- Lightweight and Excellent Value
- TPMS Compatible
- Clears OEM calipers and aftermarket
big brake kits
- Custom offsets and bolt patterns
- Fits
nearly any vehicle!
- Wheels are made to order
Custom Finishes Available:

Why Forgestar wheels are better than cast wheels
- Custom Offsets - Forgestar
wheels can be made in virtually any offset, whereas standard
cast wheels come in a set offset. This allows you to dial in
exactly how you want your wheels to sit (we can help you select the
offset you need for the look your looking for). Having custom
offsets allows for fitment of wider wheels
in stock suspension and lowered vehicles. Forgestar wheels are designed specifically for your car and it's suspension setup,
where cast wheels are designed for everyone and typically do not
take in to account lowered suspension setups.
-
Weight - Forgestar
wheels are also much lighter than cast wheels. The 19x8.5 F05 & F14
wheels both weigh an amazingly light 22.5 lbs, where a
cast wheel of this same size would weigh anywhere from 27-30 lbs.
This is a saving of roughly 5-7 pounds per wheel makes a BIG
difference in regards to handling and drivability. Reducing unsprung
weight (weight that is not supported by the car's suspension, i.e
wheels, tires, brake rotors, and brake calipers) is one of the
easiest ways to improve your car's
handling, braking, and
acceleration. As a general estimate 1 pound of unsprung
weight is equal to 10 pounds of static weight. (weight that is
supported by the vehicle's suspension). By using this ratio if you
were to replace your stock wheels that weighed 27 lbs with Forgestar
wheels you would be saving 180 lbs. in static weight!
- Strength - Flow-formed wheels
are similar in strength to that of a fully forged wheel, without the
cost. The process used to make the Forgestar wheels is the same process BBS wheels uses as
well. Forgestar wheels are also rated at 1520 lbs per wheel
which is considerably more than a cast wheels which are typically
around 1000-1200 lbs. per wheel.
- Range of Sizes - Forgestar
wheels are available in a multitude of sizes, allowing you to decide
exactly what diameter and width you want to run on your vehicle,
rather being forced to run a set staggered size with cast wheels (As
cast wheels usually are only available with one set front wheel
width, and one rear wheel width).
 |
|
Shipping
Local pickup of these wheels can be performed in the
southern California area, please e-mail a ModBargains sales
representative to schedule an appointment. Otherwise shipping is a flat
$99 to the US. International shipping quotes are available via email. |






What you need to know about the
Flow-Forming Procedure
Forgestar's flowforming process is a unique solution to a common problem
– how to make a wheel both light and strong.
|
This
specialized process begins with a low pressure type of casting and uses
a special machine that spins the initial casting, heats the outer
portion of the casting and then uses steel rollers pressed against the
rim area to pull the rim to its final width and shape. The
combination of the heat, pressure and spinning create a rim area with
the strength similar to a forged wheel. During Flow Forming, the
pressure applied to the cast rim actually changes its mechanical
properties, so its strength and impact values become similar to those of
a forged rim. That translates to up to 15% less weight when compared to
a standard cast wheel. The
resulting grain structure within the alloy of the wheel is linear,
flowing in a single direction.
This grain structure pattern, combined with the exceptional quality of
casting required for the process, gives the rim area of the wheel huge
mechanical strength, and elongation. As a result of these mechanical
characteristics, Forgestar is able to reduce the thickness of the rim
area resulting in reduced weight, without compromising strength and
resistance to impact.
So in a nutshell, the process makes the
wheels:
-
Almost as strong as forged wheels
-
Lighter than cast wheels
-
Customizable to a range of offsets and
bolt patterns
-
A great value for the price
|
 |
 |
Pictures of the Flow-Forming Process:
Forgestar has
long been an advocate for wheel durability testing. They strongly
believe that any issue regarding consumer safety is an important one.
They want every customer contemplating the purchase of Forgestar wheels
to know that it has been carefully engineered by the Forgestar team and
thoroughly tested by independent third-party testing laboratories.
Actual test
reports from independent third-party test laboratories, such as
Standards Testing Labs
(STL), have been provided by Forgestar.
The most common
test standards used are those published by SAE (J2530) and TUEV
Rheinland (Germany). PDF files of these actual test reports are provided
below as well as an explanation of how the tests are performed and what
the results mean to you as a consumer.
They send every
width in each wheel design family with the offset configuration that
presents the greatest testing challenge and subject it to the equivalent
of a full product lifetime of stress in a third-party laboratory. In
this way, it is ensured that the recommended wheel fitment is safe at
maximum rated load. |
FO5 WHEEL TEST DATA
STL REPORT 19x8.5 (PDF 35K)
STL REPORT 19x9.0 (PDF 35K)
STL REPORT 19x10 (PDF 35K) |
F14 WHEEL TEST DATA
STL REPORT 19x8.5 (PDF 35K)
STL REPORT 19x9.0 (PDF 35K)
STL REPORT 19x10 (PDF 35K)
STL REPORT 19x11 (PDF 35K) |
Forgestar has two available center cap choices:
carbon fiber caps, or BMW center caps (+$50).
Carbon Fiber Center Cap




BMW Center Cap
Please note BMW center caps are an additional
$30



|
|
|
