Product Info
- Air Struts have a complete bolt on design, and
have a 12 click adjustable monotube damper
- Allow for a 3-5" drop, depending on your
application
- Synthetic Rubber Air Springs
- Fully Threaded Damper for an additional 2" of
static travel
- Spanner Wrench Included
- 1/4" Compression Fittings
The struts included in the kit are complete bolt-ons, and have a 12
click adjustable monotube dampener. Depending on your set up, the
struts allow for a 3-5" air spring travel, and have a fully threaded
damper for an additional 2" of static travel. 1/4" Compression
fittings are included, and as is a spanner wrench.

Pictured above is the AirREX Digital Air Management
System. This system is fully assembled and leak tested, within a
30"x12"x10.5" composite wood enclosure, pre-set up, ready for
installation. The kit includes a 2.4GHz wireless remote control with
three presets. Within the enclosure is a Viair 380C Compressor, which is
capable of up to 205PSI. Attached to the compressor is a 3 gallon
stainless steel air tank. Also included is a USB cable, power wire kit,
and cig lighter adapter.
Digital Air Management System Info
(optional)
- Fully assembled and leak tested, 30"x12"x10.5"
composite wood enclosure
- 2.4GHz wireless remote controller with 3 pressure
based presets
- Viair 380C Compressor
- 3 Gallon Stainless Steel Air Tank
- Backup Controller Included
- Power Wire Kit, USB cable, and cigarette lighter
adapter included
Fitment Guide
Year |
Model |
Top Mount Options |
Part Number |
2004-2011 |
Focus Excluding Turnier |
Front Top Mount Included, Uses stock rear |
AirREX-FD001 |
1996-2003 |
Tierra |
Includes both front and rear top mounts |
AirREX-FD002 |
2006+ |
I-Max |
Front Top Mount Included, Uses stock rear |
AirREX-FD003 |
2008+ |
Fiesta |
Front Top Mount Included, Uses stock rear |
AirREX-FD005 |
2011+ |
Focus excluding Turnier |
Front Top Mount Included, Uses stock rear |
AirREX-FD006 |
2005+ |
Mustang |
Front Top Mount Included, Uses stock rear |
AirREX-FD007 |
2011+ |
Focus ST |
Front Top Mount Included, Uses stock rear |
AirREX-FD008 |
2007+ |
C-Max |
Front Top Mount Included, Uses stock rear |
AirREX-FD010 |
AirREX Photos




AirREX USA was formed to help fill the air suspension
market in the United States. Bringing an affordable, performance minded,
and easy to install air suspension system to the US market, AirREX is
making air suspension a viable option for everyone. |
