ESS Tuning Supercharger Kit for 2007-12 BMW M3 [E90/E92/E93]

$6,995.00

Quick Overview

Sku # : ESS-Supercharger-E9X-M3-ER10
Item
Manifold Finish
Supercharger Finish
ESS Badge
Shipping

Looking for the ultimate performance modification? This ESS tuning supercharger kit will turn your 4.0L V8 into a horsepower freak, with the pull of a full blown race car.  This ESS VT1/2-535-650 supercharger system uses the infamous Vortech V3Si supercharger unit capable of 775HP.

NOTE: As of November 5th, 2012 ESS and update their E9X M3 Supercharger Kit.
Kit now includes the ESS Remote Tuning E-Flash cable & have more power

With an extremely efficient design and perfectly tuned software the ESS S54 M3 VT Series supercharger system delivers supercar performance along with the quality and reliability ESS customers have come to expect. This kit is designed as a 100% bolt on package with no irreversible custom fabrication to the vehicle.

If you have any questions about this E9X M3 ESS Supercharger please give us a call at (714) 582-3330




All ESS supercharger kits are tried and tested up to 50,000 miles on the street and track, on multiple cars, throughout the world.  This guarantees you are getting a kit that will hold together for the life of your vehicle.  ESS even goes a step further with more tests like 60+ hours on ESS load dyno, full load top speed endurance testing on the German Autobahn, and final certification laps on the Nurburgring.

ESS Tuning Supercharger Kits E9X M3 ESS Tuning Supercharger Kits E9X M3
Benefits
  • HUGE power increases!!
  • Horsepower gains from 121 - 236
  • Torque gains from 75 - 125
  • 2yr./unlimited mileage warranty.
  • 100% maintenance free operation.
  • Installation time : 6-8 hours.
  • Detailed and illustrated installation manual.

Applications

  • 2008+ E90 Sedan M3
  • 2008+ E92 Coupe M3
  • 2008+ E93 Convertible M3
System components:
  • Vortech V3Si supercharger unit.
  • Street spec bypass assembly
  • Uni-belt drive system with additional OEM quality rollers
  • 8 large Bosch Motorsport fuel injectors (spec one)
  • Perfectly optimized, dyno tweaked MSS60 ECU software with removed top speed governor, calibrated for Spec 1 injectors
  • CNC hard anodized brackets and hardware
  • K&N high flow air filter
  • High temperature casted plastic intake system for SC
  • Cast aluminum ESS intake manifold with integrated velocity stacks optimized for boost
  • High temperature silicone hoses with clamps
  • Heavy duty drive belt
  • ESS oil breather assembly designed for boost

If you have any questions about this E9X M3 ESS Supercharger please give us a call at (714) 582-3330

Available Cover Types:

ESS Tuning Supercharger Kits E9X M3

Standard ESS

ESS Tuning Supercharger Kits E9X M3

ESS Black Edition

ESS Tuning Supercharger Kits E9X M3

Arkym Carbon





Types of Kits:

E9X M3 VT1-550 Supercharger System

The E9X M3 VT1-550 supercharger system comes with an especially developed cast aluminum manifold assembly with built in velocity stacks. The VT1 non-intercooled configuration uses a similar cast aluminum manifold assembly without the integrated heat exchanger.

VT1-550 specs:
Boost pressure: 5.5 PSI
Horsepower 91 octane: 550 SAE
Horsepower 93 octane: 565 SAE
Torque 91 octane: 380ft/lbs
Torque 93 octane: 390ft/lbs

ESS Tuning Supercharger Kits E9X M3

E9X M3 VT2-585 Supercharger System

The E9x M3 VT2-585 supercharger system comes with a high capacity liquid intercooler system and especially developed cast aluminum manifold assembly with integrated heat exchanger in VT2 configuration.

VT2-585 specs:
Boost pressure: 6 PSI
Horsepower 91 octane: 585 SAE
Horsepower 93 octane: 595 SAE
Torque 91 octane: 395ft/lbs
Torque 93 octane: 400ft/lbs

ESS Tuning Supercharger Kits E9X M3

E9X M3 VT2-625 Supercharger System

The E9x M3 VT2-625 supercharger system comes with a high capacity liquid intercooler system and especially developed cast aluminum manifold assembly with integrated heat exchanger in VT2 configuration.

VT2-625 specs:
Boost pressure: 6 - 6.5 PSI
Horsepower 91 octane: 615 SAE
Horsepower 93 octane: 625 SAE

ESS Tuning Supercharger Kits E9X M3

E9x M3 VT2-650 supercharger system

The E9x M3 VT2-650 supercharger system comes with a high capacity liquid intercooler system and especially developed cast aluminum manifold assembly with integrated heat exchanger. It also features a custom crankshaft pulley system specific for the VT2-650 version.

VT2-650 specs:
Boost pressure: 8 PSI
Horsepower: 650 SAE (57% increase over stock)
Torque: 420ft/lbs
Run off 93 only

ESS Tuning Supercharger Kits E9X M3

Legal in California only for racing vehicles, which may never be used upon a highway.

If you have any questions about this E9X M3 ESS Supercharger please give us a call at (714) 582-3330
